Description

All Super Torque Belts are made with strong, black polyurethane with fibreglass tension members.

The following advantages of Bancollan Super Torque Synchronous Belts are the result from the combination of the Super Torque profile system and the use of Polyurethane with fibreglass:

  • Length stability
  • Abrasion resistance (no dust)
  • Precise synchronous running
  • No maintenance
  • Chemical resistance to oils, fats, acids and lyes
  • Use in wide temperature ranges (-30°C to + 80°C, possibly higher for short durations)

Belt construction

B01 bancollan super torque Belts STS

  1. Polyurethane backing
  2. Fiberglass tension members
  3. Polyurethane teeth

Drawing

B01 bancollan super torque Belts STS dimension
B01 bancollan super torque Belts STS marking

Standard Size

Tabelle 1: Bando Super Torque Synchronous (STS)/ PU
Typ t
(mm)
H1
(mm)
H2
(mm)
W
(mm)
R
(mm)
S2M 2,00 1,40 0,76 1,30 1,30
S3M 3,00 2,00 1,14 1,95 1,95
